Λεπτομέρειες:
|
| Σκοπός: | για αντικατάσταση/επισκευή | Υπόθεση: | Νέο |
|---|---|---|---|
| Χρήση: | Κέντρο τροχών αυτοκινήτων | Μέγεθος: | Τυπικό μέγεθος 45*84*42/40mm |
| ΟΙ ΟΧΙ.: | 44300S1AE01/ 44300S84A01/ 44300S84A02 | Εγγύηση: | 1 έτος |
| Ονομασία του προϊόντος: | Λεκάνια εμβέλειας τροχών αυτοκινήτων | Εφαρμογή: | Εστία τροχών αυτοκινήτου |
| Χαρακτηριστικό: | Σταθερή απόδοση, χαμηλή φωνή. | Υλικό: | Χάλυβα χρωμικού τύπου |
| Δονήσεις: | Τυποποιημένη δόνηση | Ακριβότητα: | Τυπική Ακρίβεια |
| Λιπαντική: | Τυποποιημένη λίπανση | Τύπος σφραγίδας: | 2RZ |
| Συσκευή: | πλαστικές σακούλες+κουτί | Αριθμός γραμμής: | Διπλό. |
Σημείωση αριθ. | Σημείωση αριθ. | Σημείωση αριθ. |
DAC20420030/29 | DAC37720437 | DAC42780045 |
DAC255200206 | DAC37740437 | DAC42800036/34 |
DAC25520037 | DAC37740045 | DAC42800037 |
DAC25520042 | DAC38700037 | DAC42800038 |
DAC25520043 | DAC38700038 | DAC42800039 |
DAC25550043 | DAC381700037 | DAC42800342 |
DAC25560032 | DAC38710233/30 | DAC42800045 |
DAC255600206/29 | DAC38710039 | DAC42820036 |
DAC256000206/29 | DAC38720034 | DAC42820037 |
DAC25720043 | DAC38720236/33 | DAC42840036 |
DAC27520045/43 | DAC38720040 | DAC42840039 |
DAC27520050 | DAC38730040 | DAC43760043 |
DAC27530043 | DAC38740036/33 | DAC43770042/38 |
DAC27600050 | DAC38740236/33 | DAC43780044 |
DAC28580042 | DAC38740036 | DAC43790041/38 |
DAC28580044 | DAC38740040 | DAC43790041 |
DAC28610042 | DAC38740050 | DAC43790045 |
DAC29530037 | DAC39680037 | DAC43800038 |
DAC30580042 | DAC39680737 | DAC43800040 |
DAC30600037 | DAC39720037 | DAC43800050/45 |
DAC30600337 | DAC39740039 | DAC43820045 |
DAC30630042 | DAC39740036/34 | DAC43/45820037 |
DAC30640042 | DAC39/41750037 | DAC44825037 |
DAC30680045 | DAC40700043 | DAC44840042/40 |
DAC32720345 | DAC40720036/33 | DAC45770050/45 |
DAC34620037 | DAC40720036 | DAC45800037 |
DAC34640034 | DAC40720037 | DAC45800045 |
DAC34640037 | DAC40740036/34 | DAC45820042 |
DAC34660037 | DAC40740036 | DAC45830045 |
DAC34670037 | DAC40740040 | DAC45840039 |
DAC35618040 | DAC40740042 | DAC45840041/39 |
DAC35620040 | DAC40750037 | DAC45840042/40 |
DAC35640037 | DAC40750039 | DAC45840045 |
DAC35650035 | DAC40760033/28 | DAC458500302 |
DAC35660032 | DAC40760033 | DAC45850041 |
DAC35660033 | DAC40760041/38 | DAC45850541 |
DAC35660037 | DAC40780040 | DAC45860039 |
DAC35670042 | DAC408000302 | DAC45870041/39 |
DAC35680037 | DAC40800036/34 | DAC45880039 |
DAC35680233/30 | DAC408000381 | DAC47810053 |
DAC35720228 | DAC40800040 | DAC47850045 |
DAC35720233/31 | DAC408402538 | DAC47880055 |
DAC35720033 | DAC408406397 | DAC478800575 |
DAC35720433 | DAC401080032/17 | DAC48860042/40 |
DAC35720034 | DAC41680040/35 | DAC48890044 |
DAC35760054 | DAC42720038/35 | DAC48900042 |
DAC35770442 | DAC42720038 | DAC49840048 |
DAC35800047 | DAC42750037 | DAC49880046 |
DAC36680033 | DAC42760033 | DAC49900045 |
DAC36720034 | DAC42760038/35 | DAC51910044 |
DAC36760029/27 | DAC42760039 | DAC51960050 |
DAC37720033 | DAC42760040/37 | DAC52910040 |
DAC37720037 | DAC42770039 | DAC54960051 |
DAC37720237 | DAC42780040 |
Βάρος (KG) | Αρ. Όχι. | |||||||||
ΚΟΥΓΟ | ΑΕΠ | SKF | NSK | |||||||
DAC43760043 | 40210-2Y000 40210-3Z000 40210-4N200 | Ε | 0.70 | FW60 | 43BWD12A | |||||
Β | 0.70 | |||||||||
DAC43770042/38 | 90369-43007 | Γ | 0.70 | 43KWD04 | ||||||
DAC43780044 | 44300SNA951 | ABS | 0.78 | DAC4378AW-1CS57 | FW78 VKBA6916 | |||||
DAC43790041/38 | 44300S04A01/02 44300S5A004/008 44300S5A008 | Γ | 0.77 | DAC4379WCS64 DAC43792RSCS44 | FW171 | 43BWD08CA103 | ||||
Αριστερή ζώνη | 0.77 | |||||||||
Ε | 0.79 | |||||||||
44300SR3A02 | ABS | 0.79 | DAC4379W-1CS57 | |||||||
DAC43790041 | Γ | 0.78 | ||||||||
DAC43790045 | 43210-AG000 | Β | 0.84 | 43BWD13A | ||||||
DAC43800038 | 7M0407625 | Β | 0.75 | 579943Β | ||||||
Ε | 0.77 | |||||||||
DAC43800040 | Β | 0.80 | FW94 | |||||||
ABS | 0.80 | |||||||||
DAC43800050/45 | 90369-43005 90369-43006 | D | 0.86 | DAC4380ACS69 | Αξιολόγηση | 43BWD03CA133 | ||||
Γ | 0.86 | |||||||||
DAC43820045 | 90080-36021/78 90369-43008/09 90369-43010 | Ε | 0.96 | DAC4382W3CS79 | FW153 BAH-0032 | 43BWD06B | ||||
Γ | 0.93 | |||||||||
DAC43/45820037 | 4Α0407625/Α 4D0407625/Α 441407625Α 443407625F/H | Β | 0.76 | 567519Α 800941C | FW136 BAHB633814 BAH0011A | |||||
DAC44825037 | 3326.40 1311506080 71714473 | Β | 0.72 | VKBA3423 | ||||||
Ε | 0.73 | |||||||||
ABS | 0.73 | |||||||||
DAC44840042/40 | 44300SG0004 44300SG0000 | Β | 0.86 | DAC4484B2RSCS69 | ||||||
DAC45770050/45 | 90369-45002 | Γ | 0.80 | 46Τ090805 | 45KWD04 | |||||
DAC45800037 | Γ | 0.70 | ||||||||
DAC45800045 | 7D0498625 701407625 701501287D | Γ | 0.78 | 564725AB | BAHB311363AA | |||||
Ε | 0.80 | |||||||||
DAC45820042 | 1668557 8V411215BB | ABS | 0.82 | VKBA6636 | ||||||
DAC45830045 | Δελτίο ΕΚ 6/2011, σημείο 1. | Ε | 0.90 | DAC4583CS62 | 45BWD06 | |||||
DAC45840039 | 1249800016 0019810427 2029810127 | Β | 0.85 | DAC458439BW | 547103E | BAHB309797C BAHB633809AC | ||||
Γ | 0.84 | |||||||||
Ε | 0.86 | |||||||||
1699810127 | ABS | 0.86 | VKBA6509 BAHB636149CC | 45BWD16CA | ||||||
DAC45840041/39 | 51720-38110 51720-3A000 51720-3A101 MB633429 MB633430 MB633432 | Γ | 0.85 | DAC4584DWCS76 | BAH0160A | 45BWD03CA101 | ||||
Ε | 0.88 | |||||||||
Ε | 0.88 | |||||||||
DAC45840042/40 | 44300S1AE01 44300S84A01 44300S84A02 | Β | 0.86 | FW145 | 45BWD07BCA78 | |||||
Ε | 0.86 | |||||||||
44300S1AE01 44300S9A003 | ABS | 0.88 | 45BWD12J | |||||||
DAC45840045 | 7T41-1215BA 7T4Z-1215B 90363-A0001 90080-36193 GP9A33047 | Ε | 0.95 | DAC4584W1CS81 | FW50 | 45BWD10ACA86 | ||||
DAC458500302 | 6765406 5025900 92VB1225BA | Β | 0.63 | VKBA1466 | ||||||
DAC45850041 | 31221095702 33411090505 33411137685 33411468904 33411468926 | Γ | 0.93 | 580191 | BAHB633960 | |||||
Ε | 0.95 | |||||||||
DAC45850541 | ABS | 0.95 | ||||||||
DAC45860039 | ABS | 0.95 | ||||||||
DAC45870041/39 | Ε | 1.00 | DAC4587W | 45BWD20CA64 | ||||||
DAC45880039 | 7701469682 7701207358 7701208427 4412598 93161059 | ABS | 1.10 | VKBA3648 | ||||||
DAC47810053 | Ε | 0.86 | ||||||||
DAC47850045 | 3L2Z1215AA 6L2Z1215A 3L241215AA 6L241215AA | Ε | 0.90 | 559431Α | ||||||
DAC47880055 | 4432022 ΜΜ5133047 | Ε | 1.25 | 47KWD02A | ||||||
DAC478800575 | 90369-47001 4245128010 9052193003 | Ε | 1.35 | Πληροφορίες σχετικά με την εφαρμογή του παρόντος κανονισμού: | ||||||
DAC48860042/40 | 44300-SDA-A51 44300-SDA-A52 | Αριστερή ζώνη | 1.20 | FW48 | 48BWD02 | |||||
ABS | 1.20 | |||||||||
DAC48890044 | 90369-48001 44300-S3V-A01 44300-S3V-A02 44300SP0004/08 | Β | 1.30 | DAC4889W2RSCS94 | Ασφάλεια | FW147 | 48BWD01 | |||
DAC48900042 | 44300S0XA01 | Ε | 1.30 | FW133 | ||||||
DAC49840048 | 11062176 9023500068 9023501410 | Β | 0.84 | DAC498448WCS47 | BTHB319129DE | |||||
Ε | 0.85 | |||||||||
Ε/ΕΔ | 0.88 | |||||||||
DAC49880046 | 2203300051 2209810027 1409810427 1633300051 | Ε | 1.00 | 572506E | FW187 | 49BWD01BCA116 | ||||
DAC49900045 | 31213413946 31226751978 31226758233 31226783913 | Ε | 1.15 | 805621 | ||||||
DAC51910044 | 44300SWNP01 | ABS | 1.05 | |||||||
DAC51960050 | 7L0498287 95534190100 | ABS | 1.35 | 805209Β | FW33 | |||||
DAC52910040 | ABS | |||||||||
DAC54960051 | 90369-54002 90080-36071 | Ε | 1.30 | Πίνακας I. | FW189 | |||||
